1 Meter 1000mm Stroke Linear String Pot Encoder Sensor 6 Digit Digital Meter

HB961 Counter/Raster Table input singal：switch、pluse（Low pluse：-30V~+0.6V;High pluse：+4V~+30V） External sensors: photoelectric tube, near the switches,Hall sensors, angle, line grating displacement sensor, encoder The current total value, set the count to alarm values, set parameter values count-down function is not lost Draw-wire position sensor-- CESI-S1000 push pull Series Features: compact size, rugged construction, easy to install push pull A B Z signals The cylinders, testing machines and other industry has achieved large-scale applications, reliability The counter display: standard 96 × 48 × 82mm, 0 . 56 inches 6 digitals display Outside the instrument to the sensor for the 5V,24V Power supply: 85-260VDC/AC Magnification range: 0.000 to 999.999 Display range: -199999 to 999999 Set zero with external switch control Installation: Snap Optional three kinds of relay output. Ratio can be set, determines the ratio between input signal and displayed value. Can automatically reset the time delay. Application areas: Linear guide system, the direct determination of the guide element, such as: the length limit, gantry cranes, level measurement Hydraulic system, with the piston-oriented systems or hydraulic cylinder, the displacement sensor deflection of these devices to collect data How to connect the encoder to HB961 Counter
